HTB-1100C là bộ chuyển đổi quang điện , tốc độ 10/100Mbps, đầu nối SC, cáp quang multimode khoảng cách 2km
Type
Fiber type
Connector
Wavelength
TX power
Sensitivity
Max.distance
Link Budget
HTB-1100C
multimode
ST/SC
850/1310nm
-20~-12dBm
-30dBm
2km
10dBm
netLINK Series Fiber Media Converter is the conversion equipment of Ethernet optical-electronic signals between 10/100M UTP interface (TX) and 100M Fiber interface (FX). The traditional 10/100M Fast Ethernet can be extended to the distance of 120km through optical fiber link. The performance and quality of the products are excellent because of adopting latest IC. 6 Group LED indicated lights could fully monitor the working conditions of Converters. It is easy for users to observe the network operations. The Series products with reasonable price are especially designed for network users.
Feature
Auto negotiation function allows UTP port to select the transmission mode of 10/100M and Full Duplex or Half Duplex.
UTP port supports MDI/MDI-X auto crossover.
Multiple optical interface to be chosen: SC,ST or FC,singlemode/multimode
Supporting 1552 Byte packet
Internal circuit of prevented thunder could greatly reduce damage of the converter caused by thunderbolt induction.
Design of internal or external power supply for selection by user
Specification
Operating standards: IEEE802.3u, 10/100Base-TX and 100Base-FX
MAC address table: 1K
Connector:
UTP: RJ-45 10/100Mbps;
Fiber: ST/SC/FC 100Mbps
Cable:
UTP: Cat. 5 UTP (the max distance up to 100m)
Fiber (Multimode): 50/125, 62.5/125μm(the max distance up to 2km or 5km)
Fiber (Singlemode): 8.3/125, 8.7/125, 9/125, 10/125μm(the max distance up to 20 -120km)
Flow Control
Full Duplex: Supporting standard IEEE802.3x
Half Duplex: Backpressure
LED: Power, FX FDX, FX Link/Act, TX 100, TX FDX, TX Link/Act.
Power: AC 110V-240V to DC 5V; DC 48V to DC 5V.
Ambient Temperature: 0 ～ 70℃
Humidity: 5% ～ 90%
Dimensions:
Internal power: 30×110×140mm
External power: 26×70×93mm
Order Information
Type
Fiber type
Connector
Wavelength
TX power
Sensitivity
Max.distance
Link Budget
HTB-1100C
multimode
ST/SC
850/1310nm
-20~-12dBm
-30dBm
2km
10dBm
HTB-1100S-25
singlemode
ST/SC
1310nm
-14~-8dBm
-32dBm
25km
18dBm
HTB-1100S-40
singlemode
SC
1310nm
-8~-3dBm
-33dBm
40km
25dBm
HTB-1100S-60
singlemode
SC
1310nm
-3~0dBm
-38dBm
60km
35dBm
HTB-1100S-80
singlemode
SC
1550nm
-8~-3dBm
-35dBm
80km
27dBm
HTB-1100S-100
singlemode
SC
1550nm
-5~0dBm
-36dBm
100km
31dBm
HTB-1100S-120
singlemode
SC
1550nm
-3~3dBm
-38dBm
120km
35dBm
